Pneumatic Noise Reduction Cage Guided Control Valve

Introduction

The Pneumatic Noise Reduction cage guided control valve can reduce the noise of compressible fluid. In order to adapt to gas throttling, diffusion, and expansion, there are many symmetrical small holes on the sleeve to reduce pressure drop. The valve core adopts a pressure-balanced structure. The fluid channel is S-streamline, and it is also provided with a guide vane to improve the balanced flow of fluid around the sleeve so that the pressure drop loss is small, the flow rate is large, and the noise is low. The leakage of the regulating valve conforms to the ANSI B16.104 standard. The regulating valve is equipped with a multi-spring membrane actuator, which has a compact structure and a large output force.

Features

1. It is widely used in the automatic control process of petroleum refining, petrochemical, chemical fertilizer, general chemistry, steel, metallurgy, papermaking, electric power, light industry, etc.

2. The Pneumatic Noise Reduction Cage Guided Control Valve uses a sleeve-guided design and a balanced spool for good dynamic stability and is suitable for harsh conditions.

3. Jet impingement and turbulence are controlled within the cage, so this sonic coefficient reduces and changes the spectrum of the noise produced.

4. The porous sleeve replaces the standard sleeve, so all parts except the sleeve structure can be replaced.

5. The robust stainless steel housing design allows the Pneumatic Noise Reduction Cage Guided Control Valve to work in harsh working environments and last longer.

Body Face To Face Lenth:
