Electric High Pressure Control Valve

Product Information

The electric high pressure control valve consists of an electric actuator and a high-pressure valve body. The regulating valve adopts the form of cage throttling to share the pressure difference, which reduces the damage of cavitation, erosion and torsional flow, and greatly improves the service life of the regulating valve, especially in the urea system. 2-3 times. The electric actuator is an integrated structure with a servo amplifier inside, and the valve opening can be controlled by inputting the control signal (4~20mADC or 1~5VDC) and power supply, so as to adjust the working parameters such as pressure, flow rate, liquid level and temperature.

The body of the electric high pressure control valve is a straight-through type, the valve core is a single-guide structure, the valve body flow path is simple, and the resistance is small. The imported electric high-pressure regulating valve is especially suitable for the adjustment of high viscosity, fluid containing suspended solids and granular media, which can avoid coking and sticking blocked. The electric high pressure regulating valve as a whole has the characteristics of sensitive action, simple connection, large flow, small volume and high adjustment accuracy.

Body Face To Face Lenth:
